Z-astragal

Z astragals add security and cover gaps between doors.

  • usually mounted to inactive door leaf
  • supplied with countersink holes for flat head screws
  • contains strike, flush bolt, or other hardware preps as needed
  • standard dimensions are:
    • height is 1 inch less than door opening
    • width is 1 53/64 inches with ¾ inch legs
    • 16 gauge thickness
    • screw holes 1 1/2 inches from each end, 3 ½ inches above and below hardware cut outs, and maximum 12 inches on center
  • cold rolled steel or A60 galv.

Don’t see what you need here?  Contact our sales team and tell us what you need.
